보쉬 GBH2-21 분해도 (3611BA60B0)

제품이미지

7 베어링 슬리브

266898-7

1,100

총 70개

이미지 또는 부품명 클릭시 상세정보 조회

0 / 0

이미지	항목번호	부품번호	부품명	소요량	판매가	장바구니 담기

2	1619PS1129	Field	1	11,220
4	1607200372	Switch	1	11,220
6	2600703018	Grommet	1	1,980
7	1611035007	Cable Clip	1	1,210	품절
8	1619P16272	Nameplate	1	1,980	품절
8/1	1619P16273	Nameplate	1	1,980	품절
9	1619P16261	Manufacturer's nameplate	1	1,980	품절
9/1	1619P16275	Reference Plate	1	1,980	품절
12	1617328032	Suppression Filter	2	4,840	품절
16	1619P20535	Brush Holder	2	1,430
17	1610290108	O-Ring	1	1,430	품절
19	1610210184	O-Ring	1	1,210	품절
20	1612026151	Clamp Handle	1	9,900
22	1619PS1115	Gear Sleeve	1	1,980	품절
26	1619P20540	Hammer Piston	1	5,500
27	1619P20541	Striker	1	3,080
28	1613124084	Striker Pin	1	2,860
29	1613100034	Piston Pin	1	2,200
31	1619P09816	Retaining ring	1	1,210
32	1610508051	Rubber Bushing	1	2,860
36	1610551008	Holding Plate	1	1,430	품절
37	1610100016	Guide Disc	2	1,430
38	1616317084	Cylindrical Gear	1	12,430
39	1614601055	Retaining ring	1	1,210
40	1613100032	Straight Pin	2	1,210	품절
41	1610102072	Ratchet Disc	1	3,740
44	1610102092	Friction Washer	1	1,210
45	1611016003	Holding Plate	1	1,650
50	1619P11562	Guide Bushing	1	6,380	품절
51	1610021004	Shift Plate	1	1,210
52	1610021006	Shift Plate	1	1,210
53	1610021005	Shift Plate	1	1,210
54	1613023005	Guide Rod	1	1,430
65	1610210070	O-Ring	1	1,980
66	1619P20537	Bracket	1	1,210
67	1619P20547	Insulating Cap	1	1,210
68	1619P20548	Insulating Cap	1	1,210
69	1619P20702	Change-Over Switch	1	1,210
71	2603490023	Torx Oval-Head Screw	5	1,210
72	1619P09645	Torx Oval-Head Screw	4	1,210	품절
73	1619P00220	Torx Oval-Head Screw	4	1,210
74	1619P00219	Tapping Screw	4	1,210	품절
75	1614643025	Compression Spring	1	1,210
76	1614643023	Compression Spring	1	1,210
78	1619P20563	Tapping Screw	2	1,210
651	2603001009	Depth-Gauge	1	3,080
691	1615438409	Lock	1	3,960
691	1615438431	Lock	1	3,960
700	1617000154	Drill Chuck Shank	1	24,200
700/1	2603421207	Countersunk-Head Screw	1	1,430
701	1608571088	Chuck	1	21,450
701/1	2607950007	Chuck Wrench	1	3,960
801	1619P16274	Motor Housing	1	14,190
803	1619P16276	Armature	1	21,450
810	1617000525	Carbon-Brush Set	1	6,930
818	1619P16278	Intermediate Flange	1	14,190
821	1619P16280	Hammer Pipe	1	49,720
822	160202508X	Auxiliary Handle	1	12,430	품절
822120	160202507H	Auxiliary Handle	1	6,930
822124	1611316021	Clamping Band	1	2,200
822125	1613490002	T-Head Bolt	1	2,860
822802	1617000475	Support clamp	1	6,380
824	1619P16282	Jack Shaft	1	30,140
843	1619P16284	Gear Housing	1	18,480
856	16170006D3	Protection Sleeve	1	6,930
870	1619P16327	Connecting Cable	1	5,500
892	1615430001	Grease Tube	1	14,190
893	1615430002	Grease Tube	1	36,630	품절
894	1615430020	Grease Tube	1	14,190
895	1615430019	Oil Reservoir	1	49,720
