보쉬 GCM10GDJ 분해도 (3601M270B1)

제품이미지
ZOOM OUT ZOOM IN EXTERNAL LINK
제품이미지
1

7 베어링 슬리브

266898-7

1,100

총 269개

이미지 또는 부품명 클릭시 상세정보 조회

0 / 0
이미지 항목번호 부품번호 부품명 소요량 판매가 장바구니 담기
2 1609B06246 Field 1 66,660
4 1609B06720 Switch 1 11,220

품절
5 1609B02555 Power supply cord 1 14,190

품절
13 1609B00597 Bearing 1 6,380
31 1609B00201 Wear Plate 1 3,740
32 1609B02384 Pivot 1 5,500

품절
33 1609B00204 Torsion Spring 1 8,800
34 1609B02581 Bushing 2 1,210
35 1609B00206 Wear Plate 2 1,430
36 1609B04253 Belt 1 14,190
37 1609B00208 Flange 1 6,930

품절
39 1609B00210 Flange 1 2,530
41 1609B00211 Flange Bolt 1 2,860
42 1609B00212 Washer 1 1,210

품절
43 1609B00213 Flange Bolt 4 1,210

품절
45 1609B04261 Detent 1 5,500
46 1609B00223 Screw 2 1,430
47 1609B00225 Nut 4 2,530

품절
48 1609B04262 Sliding Plate 1 1,650
49 1609B01431 Supporting foot 4 1,650
53 1609B04265 Sliding Support 1 12,430

품절
54 1609B04266 Sliding Support 1 12,430

품절
55 1609B00232 Locking Lever 1 1,430

품절
56 1609B00233 Locking Lever 1 1,210

품절
57 1609B04312 Lock Screw 1 1,980
58 1609B04313 Lock Screw 1 1,980
59 1609B00236 Shoulder Screw 1 1,430

품절
61 1609B00237 Compression Spring 2 1,210

품절
62 1609B00238 Shoulder Screw 1 1,430

품절
78 1609B04279 Scale 1 3,960
81 1609B00256 Wrench Socket 1 1,650

품절
84 1609B04257 Shaft 1 3,080
85 1609B02377 Knob 1 4,840

품절
86 1609B00275 Cover 1 1,980
87 1609B04283 Rod 1 5,500
88 1609B00277 Support bracket 1 1,980

품절
89 1609B00278 Sliding Block 1 3,080

품절
91 1609B00279 Sliding Block 1 6,930

품절
92 1609B00281 Compression Spring 1 1,210

품절
93 1609B00280 Compression Spring 1 1,210
94 1609B00282 Sliding Plate 1 1,210

품절
95 1609B00283 Cover 1 1,430
96 1609B04259 Knob 1 1,650
97 1609B04317 Support bracket 1 1,650
98 1609B00286 Cam 1 3,960
99 1609B04346 Linkage 1 5,500
101 1609B00289 Guide Bracket 1 1,210
103 1609B00291 Compression Spring 1 1,210

품절
104 1609B00292 Locking Lever 1 8,030

품절
105 1609B00293 Lever Shaft 1 3,740

품절
106 1609B00294 Cam 1 1,430
107 1609B00295 Support bracket 1 5,500
108 1609B00296 Support bracket 1 3,740
109 1609B04357 Rod 1 6,930

품절
111 1609B04358 Sleeve 1 6,930
112 1609B00299 Guide Bracket 1 1,210

품절
114 1609B04380 Cover 1 1,210

품절
115 1609B00302 Detent Pin 1 2,530
116 1609B00303 Compression Spring 1 1,210

품절
117 1609B00304 Locking Lever 1 3,740
118 1609B00305 Bolt 1 1,980
119 1609B00306 Compression Spring 1 1,210

품절
122 1609B00308 Pin 1 1,430

품절
123 1609B00309 Torsion Spring 1 1,210

품절
124 1609B04314 Pointer 1 1,430
125 1609B02988 Scale 1 2,200
126 1609B04285 Plate 1 1,650
127 1609B00313 Wrench Socket 1 1,650
129 1609B04286 Hinge 1 73,480

품절
134 1609B00335 Hinge 1 36,630
136 1609B00337 Shaft 3 8,030

품절
137 1609B00338 Shaft 2 6,930

품절
138 1609B02574 Cable Clip 2 1,430
142 1609B04387 Flange Bolt 1 1,210
143 1609B00343 Bushing 5 3,080
144 1609B00345 Locking Lever 1 6,930

품절
145 1609B00346 Clamp Spring 1 1,430

품절
146 1609B00347 Adjusting bolt 1 1,210

품절
147 1609B00348 Plate 1 2,530

품절
148 1609B00349 Shoulder Screw 3 1,430

품절
149 1609B00350 Knob 1 1,430

품절
151 1609B00351 Shoulder Screw 1 1,210

품절
152 1609B02371 Detent 1 12,430

품절
153 1609B00353 Retaining Plate 1 1,430

품절
154 1609B00354 Retaining Plate 1 1,430

품절
155 1609B00355 Brake Plate 1 1,430

품절
156 1609B00356 Spacer 3 1,210

품절
157 1609B04315 Pointer 1 1,650
158 1609B04316 Pointer 1 1,650
159 1609B00359 Adjusting bolt 1 1,650

품절
161 1609B00361 Support bracket 1 1,430

품절
162 1609B00362 Bumper 1 1,650

품절
163 1609B00363 Shoulder Screw 1 2,860
164 1609B00364 Shaft 1 4,840
167 1609B00367 Screw 1 1,650

품절
168 1609B00368 Rubber Plug 1 1,430

품절
169 1609B00369 Rubber Plug 1 1,430
172 1609B00382 Knob 1 3,080
174 1609B04269 Plate 1 1,210
175 1609B04385 Output Shaft 1 4,840
176 1609B04296 Gear 1 6,930
177 1609B04297 Output pinion 1 6,380
178 1609B04298 Pulley 1 6,380
179 1609B04299 Belt Cover 1 4,840

품절
181 1609B00390 Button 1 1,430

품절
182 1609B00391 Locking Pin 1 1,650

품절
183 1609B00392 Compression Spring 1 1,210

품절
186 1609B04485 Trigger 1 1,650
189 1609BP7059 Connection Block 1 1,430
194 1609B00417 Compression Spring 1 1,210
195 1609B02400 Cable Sleeve 2 1,210
196 1609B00419 Rubber Pad 1 1,210

품절
197 1609B02406 Connector 1 1,210

품절
198 1609B04304 Safety Cover 1 26,840

품절
203 1609B04303 Safety Cover 1 1,430
204 1609B04310 Linkage 1 4,840
205 1609B00448 Shoulder Screw 1 2,200

품절
206 1609B00449 Bushing 1 1,210
212 1609B00454 Screw 5 1,210
213 1609B00455 Bushing 1 1,210

품절
214 1609B02467 Bumper 1 1,210

품절
215 1609B00457 Washer 1 1,210

품절
216 1609B00458 Quick-Lock 2 1,210

품절
218 1609B00460 Bushing 1 1,210
219 1609B02583 Intermediate Flange 1 18,480
222 1609B00476 Baffle 1 2,530

품절
223 1609B00478 Brush-Cover 2 1,210

품절
224 1609B00479 Insert 2 1,210

품절
225 1609B00480 Rubber Bushing 1 1,650
228 1609B04318 Dust container 1 6,380
229 1609B04319 Rubber Plate 1 1,650
231 1609B00505 Connector 1 6,380
232 1609B00506 Dust Bag 1 8,030
235 1609B00523 Rubber Pad 1 1,980

품절
238 1609B01538 Cable Tape 1 1,210

품절
239 1609B00533 Rubber Bushing 1 1,210

품절
240 1609B04302 Safety Cover 1 1,430
243 1609B00543 Warning Plate 2 1,980

품절
244 1609B02120 Sticker 1 1,650
245 1609B02119 Sticker 1 1,650
248 1609B00549 Warning Plate 3 1,980
253 1609B02122 Sticker 2 1,980
255 1609B00582 Clip 4 1,210

품절
256 1609B00583 Shrinkable Tube 1 1,210

품절
257 1609B00592 Key 1 1,430

품절
258 1609B00593 Key 1 1,430
259 1609B00594 Ball 1 1,210

품절
262 1609B00596 Bearing 1 8,800
263 1619P03937 Groove ball bearing 1 4,840

품절
265 1609B00601 O-Ring 1 1,430
266 1609B00602 Bolt 1 1,430

품절
267 1609B00603 Lock Nut 1 1,210

품절
268 1609B00604 Lock Nut 1 1,430

품절
269 1609B00605 Lock Nut 4 1,210

품절
271 1609B00608 Lock Nut 1 1,210

품절
272 1609B00609 Bolt 2 1,210

품절
273 1609B00610 Screw 4 1,430
274 1609B00612 Screw 5 1,210
275 1609B00614 Set screw 1 1,210
276 1609B00615 Set screw 2 1,650

품절
277 1609B00616 Set screw 1 1,210

품절
279 1609B00618 Set screw 2 1,430

품절
281 1609B00620 Set screw 4 1,210

품절
282 1609B00621 Set screw 1 1,430

품절
283 1609B00622 Rivet 6 1,210

품절
284 1609B00623 Screw 4 1,210
285 1609B00624 Screw 2 1,210
286 1609B00625 Screw 4 1,210

품절
287 1609B00628 Screw 4 1,210
288 1609B00627 Screw 6 1,650
289 1609B00630 Screw 3 1,210
291 1609B00745 Screw 1 1,210

품절
292 1609B00631 Screw 1 1,430
293 1609B04311 Screw 3 1,210
294 1609B00633 Screw 2 1,210
295 1609B00634 Screw 4 1,210
296 1609B00636 Tapping Screw 6 1,430
297 1609B00637 Tapping Screw 5 1,210
298 1609B00638 Spring Pin 1 1,210
301 1609B00641 Retaining ring 1 1,430
302 1609B00642 Retaining ring 4 1,210
303 1609B00643 Retaining ring 1 1,210

품절
304 1609B00644 Retaining ring 1 1,650
305 1609B00645 Screw 2 1,210

품절
306 1609B00647 Screw 9 1,430
308 1609B00650 Screw 1 1,210
310 1609B00653 Screw 3 1,210
311 1609B00654 Screw 4 1,210

품절
312 1609B00655 Screw 4 1,210

품절
313 1609B00656 Screw 2 1,430

품절
315 1609B00658 Spring Washer 1 1,210

품절
316 1609BP7042 Washer 2 1,210
317 1609B00661 Washer 2 1,210

품절
318 1609B00662 Washer 5 1,430
320 1609B00664 Washer 2 1,210

품절
321 1609B00665 Washer 1 1,210

품절
322 1609B00667 Washer 5 1,210

품절
323 1609B00669 Washer 5 1,210
324 1609B00670 Washer 1 1,430
325 1609B00672 Lock Nut 1 1,210
326 1609B00673 Lock Nut 2 1,210

품절
327 1609B00674 Washer 2 1,210

품절
328 1609B02105 Washer 1 1,210
329 1609B00678 Screw 2 1,210
330 1609B00680 Screw 1 1,210

품절
331 1609B00681 Thrust Bearing 1 3,740

품절
332 1609B00682 Screw 3 1,210

품절
333 1609B04227 Adjusting Nut 1 1,210
334 1609B02145 Hexagon Bolt 1 1,210
335 1609B00687 Retaining ring 1 1,210
336 1609B00688 Washer 1 1,210
337 1609B00689 Screw 2 1,430
338 2610919073 Brake Plate 1 5,500

품절
339 2610919281 Washer 4 2,530

품절
340 1609BP7124 Roller 2 1,430
341 1609B00370 Shaft 1 1,430

품절
342 1609B00690 Retaining ring 1 1,210

품절
343 1609B00691 Nut 1 1,650
345 1609B00288 Washer 1 1,210
351 1609B02572 Cable Clip 1 1,430

품절
352 1609B00371 Shoulder Screw 1 2,200

품절
354 1609B00676 Washer 1 1,430

품절
356 1609B04309 Cable Guard 1 1,650
362 1609B02429 Screw 1 1,210
363 1609B02430 Screw 1 1,210
365 1609B04388 Label 1 1,210
366 1609B04389 Label 1 1,210
368 1609B02991 Knob 2 1,210
369 1609B00813 Ring 1 1,210

품절
378 1609B02383 Shaft 1 3,960

품절
379 1609B02380 Carrying Handle 2 3,080

품절
380 1609B02381 Handle Plate 2 3,960

품절
391 1609B04351 Junction Box 1 1,430
394 1609B04352 Junction Box 1 1,430
396 1609B00325 Module Holder 1 1,430
397 2610233020 Soft Start-Up Module 1 12,430
399 1609B02995 Housing Cover 1 1,210

품절
401 1609B02189 Screw 1 1,210

품절
403 1609B00482 Tapping Screw 2 1,210
418 1609B04486 Linkage 1 1,210
419 1609B03777 Set screw 2 1,210

품절
421 1609B04865 Button 1 1,210
422 1609B00780 Screw 4 1,210
423 1609B04225 Plain Washer 4 1,210
427 1609B05115 Cable 2 1,650
435 1609B01530 Compression Spring 1 1,210
450 1609B00652 Screw 3 1,210

품절
457 1609B04356 Washer 1 1,210
461 1609B04263 Support Plate 2 2,530
462 1609B04264 Support Plate 2 2,530
463 1609B04268 Cover 1 1,210
466 1609B02986 Rivet 3 1,210
801 1609B02302 Motor Housing 1 36,630

품절
802 1609B02310 Detent Pin 1 2,860

품절
803 1609B02973 Armature 1 102,190

품절
810 2610021311 Carbon-Brush Set 1 9,900
812 1609B02998 Suppression Capacitor 1 1,430
827 1609B02316 Bearing 1 11,220
831 1609B02303 Hinge 1 66,660

품절
832 1609B02304 Hinge 1 54,670

품절
833 1609B02305 Hinge 1 44,880
834 1609B06203 Adjustable screw clamp 1 8,800

품절
835 1609B02306 Hinge 1 60,610
836 1609B04324 Gear Box 1 11,220
844 1609B04341 Table 1 169,070
845 1609B04336 Base 1 133,870

품절
847 1609B04349 Arm 1 73,480

품절
848 1609B04350 Protection cover 1 21,450
849 1609B04323 Plate 1 3,080

목록에 없는 부품은 단종되었거나 제조사에서 공급하지 않는 부품입니다.
